Standard dimensions in mm
|
Diameter D
|
Quantity of segments N
|
Steel core thickness E
|
Segment dimensins L x T x X
|
|
200
|
12
|
1.2
|
|
|
230
|
|
|
|
|
250
|
|
|
|
|
300
|
18
|
1.8
|
40 x 3.2 x 10
|
|
350
|
21
|
2.2
|
40 x 3.4 x 10
|
|
400
|
28
|
2.5
|
40 x 3.8 x 10
|
|
450
|
32
|
2.8
|
40 x 3.8 x 10
|
|
500
|
36
|
2.8
|
40 x 3.8 x 10
|
|
550
|
40
|
3.5
|
40 x 4.8 x 10
|
|
600
|
42
|
3.5
|
40 x 4.8 x 10
|
|
650
|
46
|
4.0
|
40 x 5.3 x 10
|
|
700
|
50
|
4.0
|
40 x 5.3 x 10
|
|
750
|
54
|
4.0
|
40 x 5.5 x 10
|
|
800
|
57
|
4.5
|
40 x 5.5 x 10
|
|
900
|
64
|
4.5
|
40 x 5.7 x 10
|
|
1000
|
70
|
4.5
|
40 x 7.0 x 10
|
|
1100
|
74
|
4.5
|
40 x 7.0 x 10
|
|
1200
|
80
|
5.5
|
40 x 8.0 x 10
|
|
1300
|
88
|
5.5
|
40 x 8.0 x 10
|
H - according the requirements
NOTE! We can produce the saws of non standard dimensions.
Bond: sintered metal M
Order example: type D x H kind of concrete
1A1RC 1100 x 50 pretensioned prestressed concrete
Application:
- pretensioned prestressed concrete, reinforced fresh concrete, fresh concrete, standard concrete
